Asphalt Snow Melting Cables/Mats

For North America Range
Contact us...

Asphalt Snow Melting Cables (SMC-FE) and Asphalt Snow Melting Mats (SMM-FE) are special cables with enhanced temperature withstand ability and mechanical strength. These can be used for embedded in concrete, asphalt drive-ways, pavements, roads, parking-bays, when hot asphalt is directly poured on the cable while laying.

Construction

Asphalt from the asphalt machine in general has a temperature of 170-220 °C. SMC-FE cables and SMM-FE mats are suitable for withstanding this temperature for up to 10 minutes. The cable is developed according to IEC 60800 Class C, which means that the cable has deformation strength of 2000N.

The ThermoTAR range consists of a resistance element provided with primary high temperature polymer insulation, earth screen and secondary insulation of high temperature material.

Heating cables could be single conductor with approx. 6.5mm outer diameter terminating on cold leads at two ends of the cable or it could be twin conductor with approx. 7.5mm outer diameter and terminating on cold leads at one end of the cable. SMC-FE and SMM-FE comes with a standard 5.0 m length cold lead.

Features

Compliance	Standards: IEC 60800 (Class M2), CSA-C22.2 No. 130, IEEE 515.1, UL 515, UL 1673
Approvals	Certified by SGS Fimko, EAC & CSA
Cost-Effective	Suitable for direct Asphalt application – thus reducing laying costs.
Safety	Thermostat backed by optional over current protection and GFCI – ensuring total protection and safety.
Range	A wide range of various sizes in various lengths ensure suitability to various layouts.
Application	used for ice and snow melting of outdoor area and other applications with direct embedding in asphalt.
Custom-built	We also offer custom designs of a product to suit individual requirements. We can design for various dimensions, heat loads and voltages.

Specifications

Standard Wattage	30W/M for SMC-FEand 350 W/Sq.m for SMM-FE,230 V
Maximum Wattage	40W/M for SMC-FE ,300/500V
Standard Width of the Mat	400 mm
Standard Cold lead length	5.0 M.
