Sticky Floor Heating Mats (SFHM) are suited to generate heat underfloor, wooden or laminate floors in bathrooms, kitchens, entry-ways and sun rooms. Very thin product is what makes them ideally suited for renovation of homes, apart from green-field construction.
The ease of installation makes them an ideal DIY 'Do-it-Yourself' kit without technicians for planning their layouts. You can avoid spoiling the aesthetics of room with unsightly radiators or convector heaters, by using Sticky Floor Heating Mats.
Construction
SFHM comprise of flexible and robust fiber-glass mats / Textile mat that carry thin heating elements uniformly fixed on it. These elements are provided with primary high temperature polymer insulation, earth screen and sheathing of polyolefin (LSZH) / PVC / high temperature polymer as desired. Heating cables could be single conductor with approx. 2.2 mm outer diameter and terminating on cold leads are power cables at both ends of the mat or could be twin conductor with approx. 3.1 mm thickness and cold leads terminating at one end of the mat.
It is available in predetermined lengths with cold tail - prefabricated & tested in a carefully controlled factory environment.
Features
| Variants | Sticky Floor heating Mat / Textile Mat / Floor heating Mat. |
| Compliance | Standards: EN / IEC 60335, EN 62233, IEC 60800, VDE 0700, CSA - C22.2 No.130, UL1683. |
| Approvals | Intertek SEMKO, SGS Fimko, VDE, TUV, EAC & UL. |
| User-friendly | Works from under the tiling, silent and unobserved. |
| Cost-effective | Under floor heating provides heat where required, resulting in optimal heat utilization and minimal losses. |
| Flexibility | Can be laid on any area, or any floor layout, as may be desired. And have cut & turn facility to fit in irregular shapes of floor. |
| Comfort | Close and uniform spacing of heating cable, associated with thermostat controls to select temperature requirements, provides higher comfort levels. |
| Safety | Thermostats backed by optional over current protection and GFCI ensures total protection and safety. |
| DIY | Do-It-Yourself kits, with instruction manuals, make them very user-friendly. |
| Range | Standard range of heat loads available in 100 W/Sq.M, 150 W/Sq.M & 200 W/Sq.M. Also various sizes for different kinds / sizes of flooring available as per given product range. |
| Custom-built | We also offer custom designs of product to suit individual requirements. We can design for various dimensions, heat loads and voltages. |
Specifications
| Standard Wattage | 100 W/Sq.M, 150 W/Sq.M and 200 W/Sq.M , 230 V |
| Standard width of the mat | 500 mm. |
| Standard Cold lead length | 3.0 mtr |
#Hindustan Heating Industries reserves the right to modify the specifications in line with future improvements, updated standards or updated certifications.
The floor heating mat is also available with invisible hot and cold connection as an additional feature.
