Concrete Curing Cable

For North America Range
Contact us...

Concrete Curing Cable (CCC-T) is a specialized solution specifically engineered to facilitate the rapid curing of concrete floors in new homes, as well as outdoor applications such as driveways, parking lots, and gutters. These cables are designed to effectively and efficiently accelerate the curing process, ensuring optimal results in a timely manner. With their exceptional performance and versatility, CCC-T cables are well-suited for both indoor and outdoor large areas, making them an ideal choice for professional applications.

Construction

In addition, the Concrete Curing Cable (CCC-T) cables are highly durable and resistant to harsh weather conditions, ensuring long-lasting performance and reliability. Their innovative design allows for easy installation and maintenance, saving both time and effort for contractors and homeowners alike.

Furthermore,Concrete Curing Cable (CCC-T) cables are environmentally friendly, as they utilize energy-efficient technology that minimizes energy consumption while maximizing efficiency. With their numerous benefits and advantages, Concrete Curing Cable (CCC-T) cables are the go-to solution for anyone in need of efficient and reliable concrete curing.

Concrete curing cable consists of a resistance element provided with insulation, an earth screen of 100 % coverage, and outer sheathing of Polyolefin.

Features

Compliance	Standards: IEC 60800.
Approvals	SGS Fimko & EAC.
Tough & Reliable	The outer metallic sheath and the over jacket – which is suitable for UV resistant and environmental friendly, makes them suitable for outdoor application like roofs, driveways, parking lots for embedding in concrete.RoHS, REACH & IP Rating:IPX7.
Safety	100 % coverage by metallic sheath to minimize EMI.
Custom-built	We also offer custom designs of a product to suit individual requirements. We can design for various dimensions, heat loads and voltages.

Specifications

Type	Twin conductor.
Voltage	230 V
Insulation	High Temperature Insulation.
Metal Sheath	Aluminium Mylar tape with drain wire.
Outer Sheath	Polyolefin (LSZH – Low smoke Zero Halogen).
Outer Diameter	Approx. 5.5 mm.
Standard Cold lead	2.0 m , 3 core, Rubber insulated, Rubber Sheathed.
