Thermo Undertile Heating Cable /Underfloor Heating Cable (UTHC) are an alternative to floor heating mats for tiled, wooden or laminate flooring. With high heating efficiency, they are a more economical option to Floor Heating mats and suit better for irregular shaped rooms. Thermo Undertile Heating Cable /Underfloor Heating Cable (UTHC) Cable helps to maintain the aesthetics of your new interiors and their thin construction makes them apt for renovations of homes, offices, corridors or large areas. Take help of qualified technician for planning and laying your Thermo Undertile Heating Cable /Underfloor Heating Cable (UTHC)
Construction
Under Tile Heating cable (UTHC) is a series type heating cable of either a twin conductor with cold lead of standard 3.0M length on one side; or single conductor with cold lead of standard 3.0M length on both sides for power connection. The cable has resistance heating wire provided with a primary insulation of high temperature polymer then covered with earth screen and final outer sheath of polyolefin (LSZH) / PVC, high temperature polymer as desired. The final outer diameter of twin conductor cable is approx. 3.1 mm and single conductor cable is approx. 2.2 mm.
Under Tile/Floor Heating Cable is available in predetermined lengths with cold tail - prefabricated & tested in a carefully controlled factory environment.
Features
| Compliance | Standards: EN 60335, EN 62233, IEC 60800, CSA - C22.2 No.130, UL1683. |
| Approvals | Intertek SEMKO, SGS Fimko, EAC & UL. |
| User-friendly | Works from under the floor, silent and unobservative. |
| Cost-effective | Under floor heating provides heat where required, resulting in optimal heat utilization and minimal losses. |
| Flexibility | Can be laid on any area, or any floor layout, as may be desired. We manufacture cable suitable for installation on Un-coupling membrane. |
| Comfort | Close and uniform spacing of heating cables, associated with thermostat controls to select temperature requirements, provides higher comfort. |
| Safety | Thermostats with an optional over current protection and GFCI, ensures total protection. |
| DIY | Do-It-Yourself kits-UTHKT, with detailed instruction manuals, makes the Under Floor Heating Kits very user-friendly. |
| Range | A wide range of heat loads and sizes ensure suitability to all kinds of floorings. |
| Custom-built | We also offer custom designs of a product to suit individual requirements. We can design for various dimensions, heat loads and voltages. |
Specifications
| Standard Wattage | 10 W/m, 230 V. |
| Maximum Wattage | 18.6 W/m, 230 V. |
| Standard Cold lead length | 3.0 M. |
#Hindustan Heating Industries reserves the right to modify the specifications in line with future improvements, updated standards or updated certifications.
The under tile heating cables is also available with invisible hot and cold connection as an additional feature.
