Silicon Heating Cable- Constant Wattage Parallel Heat Tracer(CTL) cable is a constant wattage parallel heat tracer comprising twin parallel bus wires of multi stranded coated copper. Silicon Heating Cable- Constant Wattage Parallel Heat Tracer(CTL) are insulated with Silicon Rubber & Heating Element is wound spirally around the insulated bus and connected alternatively to the bus wires at suitable intervals, forming parallel circuits. The outer sheathing of with Silicon Rubber insulation compound makes it flexible for the application.

Construction

Silicon Heating Cable- Constant Wattage Parallel Heat Tracer(CTL) cables are designed for use in industrial refrigeration. Their great flexibility means that they can be incorporated into cold room doors. They must not be used for temperature maintenance.

To ensure that these heating elements enjoy a long service life, we recommend using a control device.

Silicon Heating Cable- Constant Wattage Parallel Heat Tracer(CTL) cable is available in predetermined lengths with cold tail – prefabricated & tested in a carefully controlled factory environment.

Features

Compliance	Standard EN 60335-1
Approvals	CE
Reliability	A uniquely designed hot to cold junction makes the termination robust, IP Rating: IPX7RoHS, REACH & UV Resistant.
Flexibility	Silicon rubber cable makes them highly flexible and easy to install, with optional braiding
DIY	SHC-CTL with clear instruction manuals makes it user-friendly.
Custom built:	We also offer custom designs of a product to suit individual requirements. We can design for various dimensions, heat loads and voltages.

Specifications

Standard Wattage	30W/M, 40W/M, 50W/M, 230V
Maximum Wattage	50W/M, 230V
Standard Cold lead length	Max. 1M
