Floor Heating Cables

For North America Range
Contact us...

Thermo Floor Heating Cables (FHC) are robust and tough cable which can be embedded in the concrete slab floors for floor heating applications. Floor Heating Cables are ideally suited for installation in large areas like homes, green houses, sports fields, warehouses, shopping malls or factories.

Construction

Floor Heating Cables comprises of a resistant element provided with a primary insulation of high temperature polymer insulation, earth screen and outer sheathing of polyolefin.

Heating cables could be single conductor with approx. 4.5 mm outer diameter and terminating on cold leads at two ends of the Heating Cable or could be twin conductor with approx. 5.3 mm outer diameter and terminating on cold leads at one end of Heating Cable. Floor Heating Cables comes with a standard 2.5M length cold lead.

Floor Heating Cables is available in predetermined lengths with cold tail - prefabricated & tested in a carefully controlled factory environment.

Features

Compliance	Standards: IEC 60800 Class M2, CSA- C22.2 No. 130, IEEE 515.1, UL 515, UL 1673.
Approvals	SGS Fimko, EAC, VDE & CSA.
User-friendly	Works from under the floor, silent and unobserved.
Sturdy	Robust High Temperature polymer insulation with earth screen enables rough usage.A uniquely designed hot to cold junction makes the termination 100% robust.
Flexibility	Can be laid on any area, or any layout, as may be desired.
Safety	Thermostats backed by optional over current protection and GFCI, ensure total protection and safety.
Custom-built	We also offer custom designs of a product to suit individual requirements. We can design for various dimensions, heat loads and voltages.

Specifications

Standard Wattage	17 W/m, 230 V.
Maximum Wattage	20 W/m, 300/500V
Standard Cold lead length	2.5 M.
